Akıllı Valf Yerleştiricisi

Valve with Aluminum actuator with Intelligent C TOP-1561 control unit to feedback PLC

Tüm Kategori

Paslanmaz çelik sanitasyon ekipmanları

Bizimle İletişim

Ms. Jasmine Zhuang

donjoy01@cndonjoy.com

86-18967799769

Şimdi iletişime geçin

Valve with Aluminum actuator with Intelligent C TOP-1561 control unit to feedback PLC

Marka Adı:	DONJOY
Model Numarası:	C-TOP-11
Adedi:	Negotiation
fiyat:	US $600 - 1,000 / Piece
Paketleme Ayrıntıları:	carton box
Ödeme Şartları:	T/T, LC, Credit Card

Ayrıntılı Bilgiler

Ürün Açıklaması

Ayrıntılı Bilgiler

Place of Origin:

CHINA

Sertifika:

CE,3A,FDA

Product Name:

Control Unit

Power:

DC.24V

Pneumatic pressure:

4-7bar

Level of protection:

IP67

Operation interface::

Key

Working pressure:

10bar

Max. Working temperature:

70℃

Max. C - TOP units:

31 C - TOP units

Vurgulamak:

pneumatic valve positioner

digital valve positioner

Ürün Açıklaması

Valve Aluminum actuator with Intelligent C TOP-1561 control unit to feedback PLC

Technical Feature

1 Input: PNP24VDC

2.Feedback output:PNP DC24V& 4-20mA

3.power Supply: DC24V±10%

4.Bus Communication:AS-I BUS

5.Accuracy: Repeat positioning accuracy≤0.2%

6.Ajusting: Single button auto-adjusting function

7.Operation mode: Manul/Automatic operation

8.Leakproof diagnostic Function

9.Display: two-section Light Color open: Green/Red, Close:red/Green

10.Strocke Range: 0-180degree

SPECIFICATION

Product Name	Intelligent valve positioner
Medium	Lubricated compressed air, inert gases
Max. Working temperature	70℃
Working pressure	1.5 bar - 7 bar (22PSI to 102PSI)
Connector	G1/8"
Level of protection	IP67
Air flow	200NL
Feature	Pneumatic actuator of double acting
Structure	Could be with Position sensor
Stroke	180degree
Max. C - TOP units	31 C - TOP units
Connecting cable	2m
AS-I BUS	max. length: 1m

Applications

C - TOP is pneumatic controller which is designed to ensure optimum control valve.

It is compatible with most PLC automatic system. In the industry of food, beverage, pharmacy,

it could be installed to all kinds of pneumatic valves such as mixture proof valve, butterfly valve, ball valve, diaphragm valve, reversing valve and globe valve etc.

Design and features

Connecting sensors with solenoid valve ( actuator ) easily, fastly and economically by AS - I BUS mastering.

Since cables are largely decreased, installation and start up become more convenient.

Besides, start time is shortened, and some hidden troubles in the installation can be avoided.Parts are same as standard C - TOP. The only changed part is the built - in card,. AS - I insulation replacement connector and the cable connector itself.

C - TOP Valve control unit - - 2014

Displacement regulating version

Model

Sensor

Solenoid valve

Power

Connection

Remarks

1421-05-S1-V1

DC. 24V

Cable connection

Single acting

1421-05-S1-V2

DC. 24V

Cable connection

Double acting

1421-05-S1-V3

DC. 24V

Cable connection

Three effects (mixture proof valve)

1421-05-S1-V1-AS

DC. 24V

AS-I BUS

Single acting

1421-05-S1-V2-AS

DC. 24V

AS-I BUS

Double acting

1421-05-S1-V3-AS

DC. 24V

AS-I BUS

Three effects (mixture proof valve)

Mechanical regulating version

Model

Sensor

Solenoid valve

Power

Connection

Remarks

1421-05-S1-V1-M

DC. 24V

Cable connection

Single acting

1421-05-S1-V1-M

DC. 24V

Cable connection

Single acting

1421-05-S1-V2-M

DC. 24V

Cable connection

Double acting

1421-05-S1-V3-M

DC. 24V

Cable connection

Three effects (mixture proof valve)

1421-05-S1-V1-AS-M

DC. 24V

AS-I BUS

Single acting

1421-05-S1-V1-AS-M

DC. 24V

AS-I BUS

Single acting

1421-05-S1-V2-AS-M

DC. 24V

AS-I BUS

Double acting

1421-05-S1-V3-AS-M

DC. 24V

AS-I BUS

Three effects (mixture proof valve)

Valve with Aluminum actuator with Intelligent C TOP-1561 control unit to feedback PLC 0

Valve with Aluminum actuator with Intelligent C TOP-1561 control unit to feedback PLC 1
